Glasswashers and dishwashers for small to medium-sized bars and restaurants. Also known as front-loading dishwashers, they are ideal for washing dishes, glasses, cutlery, and delicate glassware. They are the best option for small and medium-sized kitchens. Ideal for bars, restaurants, and cafes.

Baskets per hour: 40.
Units per hour: 720.
Diners per hour: 103.

Characteristics:

General information

• Tank capacity: 15.3.

• Basket dimensions: 500 x 500 / 500 x 540 mm.

• Useful entry height: 404 mm.

• Washing pump: 0.6 kW.
• Noise emission: max. 55 dB(A).

• Splash protection with back wall CN: IPX5.
• Maximum inlet water temperature: 60 °C.
• Required dynamic water pressure: 1.0 –10.0 / 100–1,000 bar/ kPA.

Specific data according to the software:

• Standard theoretical capacity - baskets/hour:
  • Glasses: 48.
  • Dishes: 40.

  • Cafeterias: 40.
  • Cutlery: 11.
• Theoretical capacity Short program baskets/hour:
  • Glasses: 77.
  • Dishes: 66.

  • Cafeterias: 66.
  • Place settings: 21.

• Water consumption for rinsing per wash cycle 2 UC-XL:

  • Glasses:
    • Standard: 2.2.

    • Eco: 2.0.

    • Cool: 3.4.
  • Dishes:
    • Standard: 2.2.

    • Eco: 2.0.
  • Cafeterias:
    • Standard: 2.2.

    • Eco: 2.0.
  • Covered:
    • Standard: 3.4.

    • Echo: 3.1.
• Tank temperature:
  • Glasses:
    • 62 °C.

    • Cool: 55 °C.
  • Dishes:
    • 62 °C.

  • Cafeterias:
    • 62 °C.

  • Covered:
    • 69 °C.

• Rinse temperature:
  • Glasses:
    • 65 °C.

    • Cool:
  • Dishes:
    • 85 °C.

  • Cafeterias:
    • 65–85 °C.

  • Covered:
    • 85 °C.
• Dimensions: 60 x 63.7-69.1 x 82.0-85.5 cm (Width x Depth x Height).

*1Depending on the characteristics of the installation site (inlet water temperature / electrical connection) the indicated values ​​may be reduced.

*2 Non-binding information. Actual water consumption for rinsing may vary depending on the characteristics of the installation site.

Note: For flush mounting, the following dimensional modifications must be taken into account:

Height: + 5mm
Width: +10mm
Depth: + 5mm

Removing the legs reduces the machine's height by 10mm.
b Without integrated detergent and rinse aid container, the height is reduced by 20mm on all machines.
